Product Description	C.S.A Sq.Mm	Wire Dia. Mm+/-0.02	Kg / Km
JIFB-7-XXXX	7 mm²	0.15	70
JIFB-12.5-XXXX	12.5 mm²	0.2	125
JIFB-16-XXXX	16 mm²	0.3	160
JIFB-25-XXXX	25 mm²	0.3	250
JIFB-35-XXXX	35 mm²	0.3	350
JIFB-50-XXXX	50 mm²	0.3	500
JIFB-70-XXXX	70 mm²	0.3	700
JIFB-108.6-XXXX	108.6 mm²	0.3	1086

*XXXX = Length
Length=As Per Customer Requirement
Weight Depend On Lay Pitch
Width As Per Customer Requirement
Wire Dia Can Be Used From 0.3mm To 0.12mm
Labeling Of Piece Or Reels As Per Customer Requirement
Nearest Normal Area Will Be Achieved By Changing Diameter Of The Wire
If Your Requirements Are Not Listed, Please Contact Us To Review Your Requirement
